Exhaust Fan Motor Winding Data 24 Slot 1440 Rpm. Exhaust fan motor winding data in this post we have described how to winding 24 Slot Exhaust fan motor winding.this is an 18-inch Exhaust fan and it is mostly used in industrial purpose, but a few years ago this 18-inch exhaust fan motor is also used in Heavy-duty coolers.

The Exhaust fan is 1400 rpm and has 24 slots. Its Running winding uses 26 number copper wire whose weight is around 400 Grams. And 100 TURN is put in its running winding, which is in 1–4 pitch while in 1–6 pitch the trumpet is doubled to 200 TURN. In four pitches, COIL is rotated once and in 6 pitches WINDING COIL is rotated 2 times. And the length of its COIL SIZE is around 27 inches, which you can do more work according to your own.
Exhaust fan starting pitch is one to four like bay running. 110 TURNS are put in one to four pitches and 220 TURNS in 1 to 6 pitch. And the starting wire number is 29 Numbers. The exhaust fan motor has a 6 mfd capacitor USE which is the running capacitor.

Exhaust Fan Winding Detail In Hindi.

एग्जास्ट फैन जोके 1400 आरपीएम का होता हैऔर इसके स्लॉट 24  होते। उसकी रनिंग वाइंडिंग मे 26नंबर कॉपर तार का प्रयोग किया जाता है जिसका वेट 400 ग्राम के आस पास होता है।
  और इसकी रनिंग वाइंडिंग में 100 टर्न डाली जाती है,जो के 1-4 पिच में होती है जबकि 1-6 पिच में यह तुरंस डबल होकर 200 टर्न हो जाती है. चार पिच में कएल को एक बार और 6 पिच में कएल को 2 बार घुमाया जाता है. और इसके कएल की लम्बाई 27 इंच के आस पास होती है जिसको आप अपने हिसाब से काम और ज्यादा कर सकते है।

18-inch Exhaust Fan Starting Winding Pitch Data.


 एग्जॉस्ट फैन की स्टार्टिंग की पिच रनिंग Winding की तरह एक से चार ही होती है। एक से चार पिच में  110 TURNS और एक से 6 पिच में 220 टर्न डाली जाती है। और स्टार्टिंग का तार नंबर 26 नंबर होता है.

Exhaust Fan Capacitor Value and Mfd.

Exhaust Fan Capacitor Value and Mfd.motorcoilwindingdata.com

एग्जॉस्ट फैन की मोटर में 6 mfd का कपैसिटर USE होता है जो के रनिंग कपैसिटर (Running Capacitor) होता है।

18 Inch Exhaust Fan Motor Winding Data Detail Is Here..

Core length   1 inch 5 Soot

Inner dia Meter 3″2 soot

Outer Diameter = 5 inch 5 Soot

Slots.   24

Watts 470

Rpm 1440

4 pole motor winding.

Winding Wire = Copper Wire

Capacitor 6 mfd in 220 volts to 240 volt.

Running pitch 1-4 and 1-6

Coil.     1-4 (1 baar gumana)                   [ एक बार घूमना ]

Coil.      1-6( 2 baar gumana hai)            [ दो  बार घूमना ]

3-Speed Exhaust Fan Coil Winding Data Details Here:–

SWG 32     TURN  =40
SWG 30     TURN = 35
SWG 26      TURN  =75

Running winding standard wire gauze swg = 26 Number (Copper Wire)

Coil.  1-4.        1-6

Turn   100-.      200

===========================================================
18-inch Exhaust Fan Starting Winding Data.


Starting pitch   1-4 and. 1-6


Starting winding Swg Number = 29

Coil.  1-4.      1-6

Turn 110.      220

Total coils 8pc

4 coils in running

      and

4 coils in. starting

Coil size is  = 27 INCH

(This is Three-Speed winding motor

Cooler motor 24 slot winding,

Connection =  Normal 1-4

Exhaust Fan Motor Winding Connection Diagram.

CONNECTION-DIAGRAM

Exhaust Fan Winding Video Watch Here.

https://youtu.be/gyAOCzFo7I8
18 inch Exhaust Fan Winding motorcoilwindingdata.com

EXHAUST FAN WINDING SOME ANOTHER VIDEO IS HERE.

24 Slot Exhaust Fan Winding Video.

https://youtu.be/MJXOgf8iWF8

Industrial Exhaust Fan Winding Data Video.

Exhaust Fan Cooler Motor Winding Video Watch Here.

36 Slot Exhaust Fan Winding Video Watch Here.

24 Slot Exhaust Fan Video Watch Here.

Crompton Greaves Exhaust Fan Winding Data Blue Colour Video.

4 Coil Exhaust Fan Winding Video Watch Here.
